Attwood Deck Fill f/Carbon Canister System - Angled Body Scalloped Black Plastic Cap [99DFCCAB1S]

RBP-98336

Regular price $68.99 Sale price$60.99 Save $8.00
/
Shipping calculated at checkout.

  • Low stock - 4 items left
  • Inventory on the way

Deck Fill for Carbon Canister System - Angled Body & Scalloped Black Plastic Cap

Pressure relief systems are designed with automatic diurnal emission control and overpressure relief safety valves built into the cap of the fill. The overpressure relief safety valves are engineered to release pressure above 1 psi. The high-flow vacuum valves allow fresh air to enter the fuel tank to replace the fuel being consumed by the engine. Other components of a pressure relief system are designed to ensure the tank fills to the proper level every time without spit-back or well-back.

Specifications & Technical Data

  • Material Composition: Matte black composite plastic body with a scalloped latching flip-up cap.

  • System Integration: Built specifically for marine fuel systems equipped with carbon canister emission controls.

  • Compliance & Ratings: EPA and CARB certified; meets CARB 13 CCR 2235, ISO 10088, CE compliance, and ISO 13331 nozzle retention standards. Compatible with ethanol-blended fuels.

Measurements & Dimensions

  • Overall Dimensions: Approximately 3-1/2 inches diameter × 4-1/4 inches length

  • Cutout Requirement: Mounts in a 2-inch diameter cutout hole.

  • Fastener Spacing: Four 1/4-inch diameter mounting holes spaced 1-3/4 inches center-to-center (CTC).

  • Fill Hose Compatibility: Fits a 1-1/2-inch barbed fill hose.

  • Automatic Nozzle Shutoff Flow Rate: 4 to 18 gpm

  • Product Weight: 0.31 lbs (Store default shipping package: 6 × 6 × 6 inches)

Key Features & Design

  • Diurnal Emission Control: Dual 1 psi overpressure relief safety valves built into the cap safely vent pressure while preventing fuel evaporation.

  • Airflow Management: High-flow vacuum valves allow fresh air to enter the tank as fuel is consumed.

  • Refueling Efficiency: Engineered to ensure proper filling levels without spit-back or well-back, supporting both Jerry Can and marine nozzle refueling while blocking water intrusion.

WarningWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Quick Guide (pdf)
